Product Details

Included in the box
  • Profile Pedal Deck
  • Full set of M8 bolts and nuts to mount on the rig
Specifications

• Material: 4 mm hardened steel (side plates) + 3× 40×80 aluminium profiles
• Bracket color: matte black, textured powder coating
• Profile color: matte black, powder coating
• Dimensions (L × W × H in mm): 358 × 496 × 110
• Weight (kg): 8
• Adjustments: height, angle, reverse-mount capability


SimXPro Compatibility

All cockpits built with 40×80, 40×120 and 40×160 profiles with a 500 mm inner profile spacing.

Electronics Compatibility

Compatible pedals:

• All hydraulic and load-cell pedal sets (the profiles are adjustable)

Not compatible with:

• Pedals with mounting points only on the underside → Solution: can be adapted by using 4× 40×40 corner brackets

Instruction video
Instruction video
youtu.be/HFigAkp5lxA
