COMPARE MODELS

SIMUCUBE 2 SPORT SIMUCUBE 2 PRO SIMUCUBE 2 ULTIMATE
MOTOR Direct Drive optimized ultra low torque ripple motor High response speed Direct Drive optimized ultra low torque ripple motor Maximum response speed, low inertia, Direct Drive optimized ultra low torque ripple motor
SIMUCUBE WIRELESS WHEEL™ SUPPORT Included Included Included
SIMUCUBE QUICK RELEASE™ Not Included Not Included Included
MAX TORQUE * 17 Nm 25 Nm 32 Nm
MAX TORQUE SLEW RATE 4.8 Nm/ms 8.0 Nm/ms 9.5 Nm/ms
ANGLE SENSOR 22 bit absolute 22 bit absolute 24 bit Hiperface
TORQUE OFF BUTTON Standard (Premium optional) Standard (Premium optional) Premium (with remote power switch)
POWER SUPPLY 280 W R1 2 x 280 W / R2 1 x 450 W Peak 1000 W
WHEEL BASE DIMENSIONS INCL. SQR™ 130 x 130 x 250 mm 130 x 130 x 270 mm 115 x 115 x 310 mm
MOUNTING HOLES M8 x 4 pcs threaded hole M8 x 4 pcs threaded hole 9 mm dia x 4 pcs through hole
MOUNTING HOLE PATTERN DIA 145 mm 145 mm 130 mm
FLANGE CENTERING HOLE DIA 110 mm 110 mm 110 mm
WHEEL BASE WEIGHT 8.0 kg 11.1 kg 11.3 kg
STANDARD WARRANTY 24 months 24 months 60 months
*) Torque is continuous until motor gets very hot. In preliminary testing, no-one has managed to cause torque to start throttling.
SIMUCUBE 2 SPORT SIMUCUBE 2 PRO SIMUCUBE 2 ULTIMATE
TORQUE RECONSTRUCTION PROCESSING Yes Yes Yes
STATIC FORCE REDUCTION Yes Yes Yes, in detail adjustable
NATURAL DAMPING, INERTIA AND FRICTION FILTERS Yes Yes Yes, in detail adjustable
ULTRA LOW LATENCY MODE Yes Yes Yes
TORQUE SLEW RATE ADJUSTMENT 1 – 4.8 Nm/ms 1 – 8.0 Nm/ms 1 – 9.5 Nm/ms
