01 MOZA
MOZA SR-P Pedals
- Free shipping on orders over €100
- Bundle discount included in the price
Shifter mount
02 In action
MOZA SR-P Pedals
-
Shipping
Free shipping
On every order over €100, shipped from the Netherlands.
-
Support
Real sim racers
Help from people who race themselves, usually within 2 hours.
03 Why this product
Why the MOZA SR-P Pedals?
A steel two-pedal set with a 100 kg load-cell brake, 15-bit angle sensing and direct USB connection. The MOZA SR-P Pedals in this SKU include throttle and brake pedals without a clutch. The brake combines pressure and angle sensing for progressive input, while the throttle uses a high-resolution angle sensor.
04 Specs
The numbers.
Full product description
The MOZA SR-P Pedals in this SKU include throttle and brake pedals without a clutch. The brake combines pressure and angle sensing for progressive input, while the throttle uses a high-resolution angle sensor. Direct USB connectivity lets the pedal set operate independently from the wheel base on a PC, making it suitable for mixed-brand installations as well as MOZA systems.
Why choose this product?
- The brake combines a load cell rated to 100 kg with a 15-bit angle sensor, supporting pressure-based control across the pedal stroke.
- Independent USB operation allows the pedals to be paired with compatible PC wheel-base hardware from MOZA or other brands.
Product details
Steel construction and dual-sensor brake
The pedal frame and pedal plates are made from high-strength steel. The brake measures both applied pressure and pedal angle: a load cell supports force up to 100 kg, while the 15-bit magnetic angle sensor provides 32,768 positions. MOZA uses the two signals together so the first part of the stroke can respond to movement and heavier braking can be controlled through pressure. The throttle uses the same 15-bit angle-sensing resolution.
Adjustment and mounting
Pedal spacing and face-plate height can be adjusted to suit the cockpit and foot position. An anti-slip pad is supplied for floor use, although fixed mounting is recommended when higher brake forces are applied. The two-pedal set measures 410 × 310 × 170 mm. Mechanical position should be set first, followed by calibration of travel and dead zones in the software.
Software and upgrade path
The SR-P connects directly to a PC through the supplied Type-A-to-Type-B USB cable. MOZA Pit House supports pedal-travel adjustment, input reversal, calibration and response settings. A matching SR-P clutch and SR-P Accessory Kit are available separately for drivers who need a three-pedal layout or additional brake-feel options. SR-P Lite clutch and brake-performance parts are not compatible with this system and must not be used as substitutes.
Compatibility
Platform: PC through USB.
Connection and ecosystem: independent USB pedal device that can be used with compatible MOZA or third-party wheel-base setups.
Requirements: an available USB port and a stable floor or cockpit mounting position. SR-P Lite clutch and SR-P Lite Brake Performance Kit are not compatible.
Specifications
What's in the box?
- MOZA SR-P throttle and brake pedal set without clutch
- Type-A-to-Type-B USB cable
- Toolkit
Frequently asked questions
Does this set include a clutch?
No. This SKU contains throttle and brake pedals. A compatible SR-P clutch is available separately.
Can the SR-P pedals work with another brand's wheel base?
Yes on PC. The pedals connect independently through USB, subject to the simulator accepting separate controller devices.
How does the brake measure input?
It combines a load cell rated up to 100 kg with a 15-bit magnetic angle sensor for pressure and travel measurement.
Can pedal travel be calibrated?
Yes. MOZA Pit House provides calibration, travel adjustment, input reversal and response settings.
Can I use SR-P Lite upgrades on these pedals?
No. SR-P Lite clutch and brake-performance accessories are not compatible. Select upgrades made specifically for the SR-P system.
Please note: we make every effort to display products as accurately as possible. Colours, materials and finishes may vary slightly in real life due to studio lighting, screen settings, ambient light and product characteristics.
06 In the box and assembly
From box
to first lap.
No figure it out yourself. Every build, adjustment and upgrade is filmed step by step, so you can set up and adjust your rig yourself.
SimXPro video library
Build it. Tune it.
Fix it. Yourself.
Assembly manuals, product showcases and community reviews for every SimXPro rig, in one place. New videos are added all the time.
Need a hand with setup? Real sim racers answer, usually within 2 hours.
Ask SimXProMade up your mind? Pick your options and add it to your cart.
